Different measurement options (2 components in a plane, 3 components in a plane and 3 components in a volume)
Versatile technique tailored to your needs (Planar PIV, results in 2D planes with U and V velocity components, Stereo PIV, results in 2D planes with U, V, and W velocity components and Volumetric velocimetry measures U, V, and W in a 3D volume)
Large velocity range
Large measurement domain range
High spatial resolution
High temporal resolution
Correlation-based techniques
Extensive post-processing
One software platform with interfaces and export functions
BEST FOR VERSATILITY
– A great choice for lab or industrial application
– Sucessfully used in the most demanding of applications in optical metrology, microscopy and laser diagnostics.
– Optimize the aligment of complex systems
– On and off-axis 3D MTF
KEY SPECS
– Multiple options as per focusing objectives and collimating beam sizes
– λ/200 RMS measurement accuracy in double-pass configuration
– Insensitive to vibrations and atmospheric turbulence
KEY FEATURES
Extends the capabilities of HASO RFLEX for analyzing large optics and optical surfaces such as filters, dichroic beam splitters, head-up displays, eyewear, optical windows, flat mirrors, polarization scramblers.
KEY SPECS
– 400-1100 nm wavelength
– Insensitive to vibration
– Beam 30-150 mm ф
– Up to 21,000 sampling points
– Up to 1 kHz acquisition frequency
BEST FOR VERSATILITY
– Characterize optical surfaces
– Characterize chromatic aberrations
– Analyze the transmitted wavefront of optical systems with double-pass configuration
– Optimize the alignment of complex systems
– On and off-axis 3D MTF
KEY SPECS
– Multiple options as per focusing objectives and collimating beam sizes
– λ/200 RMS measurement accuracy in double-pass configuration
– Insensitive to vibrations and atmospheric turbulence
