Showing 1–16 of 95 results

100kW diode source: High efficiency high power diode laser source

 Bernard Azout

Key Features:

  • Up to 120 kW in one line @ 940 & 980 nm
  • Up to 250 kW @ 880 nm
  • Up to 1 MW in 8 lines matric array
  • 880, 940 and 980 nm available
  • Driver available in a separate rack or integrated to the source for 100 kW version
  • Operating with non DI water from +10°C to +40°C
  • Bar pitch 400, 800 or 1.2 mm upon energy per pulse
  • Lifetime warranties from 1 to 10 Gshots upon energy per pulse

1030-1180 nm DFB laser

 Johanna Taieb

Key Features:

  • Wide wavelength lineup: 1030, 1053, 1064, 1080, 1120, 1180 nm and more
  • Stable single mode operation
  • Short pulse (picoseconds, nanoseconds)
  • 400 mW to 1 nanosecond high light power
  • 14-pin butterfly / 7-pin SMPM module
  • Picosecond pulsed driver board
  • 1060 nm gain chip for tunable laser
  • Application: Seeder of fiber laser for machining, LIDAR

1030-1180 nm DFB laser

 Johanna Taien

Key Features:

  • Wide wavelength lineup: 1030, 1053, 1064, 1080, 1120, 1180 nm and more
  • Stable single mode operation
  • Short pulse (picoseconds, nanoseconds)
  • 400 mW to 1 nanosecond high light power
  • 14-pin butterfly / 7-pin SMPM module
  • Picosecond pulsed driver board
  • 1060 nm gain chip for tunable laser
  • Application: Seeder of fiber laser for machining, LIDAR

1310 nm laser diode : 4 DFB models up to 180 mW – CW or Pulse

 Bernard Azout

Key Features:

  • Wavelength : 1310 nm or select the wavelength you need between 1250 and 1650 nm (Most 1310, 1550 and 1650 nm models are in stock)
  • 4 single-frequency DFB laser diode models up to 180 mW
  • Narrow emission linewidth of typically less than 200 kHz
  • All versions are fiber-coupled and isolated
  • Up to 180 mW CW
  • Up to 250 mW peak power
  • Down to 1 ns pulse width
  • Low noise CW emission
  • Butterfly Type-1 pinning or please ask for other pinning
  • See “Specs” window for detailed technical properties of “Diode + Driver” combo solutions

1550 nm laser diode – CW or Pulsed – DFB or Bragg up to 400 mW

 Bernard Azout

Key Features:

  • Wavelength : 1550 nm or select the wavelength you need between 1260 and 1650 nm (Most 1310, 1550 and 1650 nm models are in stock)
  • 6 models for each wavelength : 5 single frequency DFB models (2 models with ultra-narrow linewidth) and 1 Bragg grating based with >400 mW CW power
  • All versions are fiber-coupled and all DFB versions are isolated
  • Up to 400 mW CW (this high power model only available from up to 1500 nm)
  • Up to 600 mW peak power
  • Down to 1 ns pulse width
  • Low noise CW emission
  • Butterfly Type-1 pinning or please ask for other pinning
  • See “Specs” window for detailed technical properties of “Diode + Driver” combo solutions

1650 nm laser diode – CW or Pulsed – 4 DFB versions up to 100 mW

 Bernard Azout

Key Features:

  • Wavelength : 1650 nm or select the wavelength you need between 1260 and 1650 nm (Most 1310, 1550 and 1650 nm models are in stock)
  • 4 single-frequency laser diode models with narrow emission bandwidth (typical bandwidth : 160 kHz)
  • All versions are fiber-coupled and isolated
  • Up to 100 mW CW
  • Up to 200 mW peak power
  • Down to 1 ns pulse width
  • Low noise CW emission
  • Butterfly Type-1 pinning or please ask for other pinning

532-594 nm compact visible lasers

 Johanna Taieb

Key Features:

  • Wavelengths: 532, 561, and 594 nm
  • Light output: 5, 20, 30, and 50 mW
  • Low power consumption
  • Short pulse operation (nanoseconds, 50 picoseconds)
  • Compact package
  • Option: Fiber pigtail
  • Applications: Light source for biomedical equipment, sensors
