Amplified photodetector PDA030

 Miki Iluz

Key Features

  • Measured bandwidth >30MHz
  • Wide spectral response 300 – 1060 nm
  • High quantum efficiency 0.64 at 900 nm
  • Isolated BNC connector to avoid ground loops via the chassis
  • Standard M8 power connector accepting ±7V to ±15V
  • SM1 (1.035”-40) internal thread optical tube mount
  • M4/8-32 threaded holes for easy mounting

​Also available with an InGaAs photodiode for the wavelengths in the range 800 – 1700nm, details available on request.

Description

The MOGLabs PDA030 is an amplified silicon photodetector designed for demanding low-noise applications such as Pound-Drever-Hall optical cavity locking. It provides high bandwidth, high quantum-efficiency and low noise photodetection in a convenient mechanical enclosure with industry-standard connectors.

The 50Ω impedance signal is provided via an isolated BNC connector that helps eliminate ground loops via the optical table. Power is easily provided via Thorlabs-compatible M8 connector, including directly from the MOGLabs FSC fast servo controller. Optical tubes, filters and lenses are easily mounted using the standard SM1 threaded ring.
